Omnidirectional Antennas

Standard. Custom. Wideband. Rugged.

AntennaTec manufactures standard and customized omnidirectional antennas for wide-area RF coverage across communication, spectrum monitoring, UAV, defense, electronic warfare, SIGINT, ESM, ECM, RWR and specialist wireless applications.

Omnidirectional antennas provide coverage in all directions around the antenna axis, making them suitable for applications where wide-area RF transmission or reception is required.

They are commonly used in communication systems, telemetry links, spectrum monitoring, UAV platforms, mobile systems and fixed-site installations.

AntennaTec offers standard and customised omnidirectional antennas with wideband, compact, radome-enclosed and rugged options for practical deployment in demanding RF environments.

PRODUCT NO	CATALOGUE NO	FREQUENCY (GHz)	VSWR	GAIN (dBi)	POLARIZATION	POWER c.w. (W)	CONNECTOR
AT-O-0.5-3-N	AT-O-0.5-3-N	0.5 - 3	< 2:1	2-6.5	linear/vertical	100	N-type
AT-O-1.2-1.5-S	AT-O-1.2-1.5-S	1.2 - 1.5	< 2:1	> 2	linear/vertical	—	SMA
AT-O-2.1-2.4-N	AT-O-2.1-2.4-N	2.1 - 2.4	< 2:1	> 6	linear/vertical	50	N-type
AT-O-0.4-6-N	AT-O-0.4-6-N	0.4 - 6	< 3:1	—	linear/vertical	—	N-type

Speak To A Specialist About Your Requirement.
